Standard part

·Oil plate
·Splash guard
·Three jaw chuck
·Reduction Sleeve s
·Center
·Tool box and tools

·Steady rest
·Follow rest
·Four jaw chuck
·Face plate

Optional

·Quick chang tool post
·Drill chuck
·Live center
·Lead screw cover
·Foot stand

Model

CQ6123B×500

Swing over bed

230mm

9＂

Swing over cross slide

156mm

5-1/8＂

Length of work piece

550mm

19-1/16＂

Taper of spindle bore

莫氏3号

MT3#

Spindle bore

20mm

13/16＂

Range of spindle speed

100-1800r/min(50HZ)

100-1800r/min(50HZ)

Longitudinal feed per revolution of spindle

0.127mm,0.177mm/rev

0.005＂0.0069＂

Range of inch threads to be cut

8-56T.P.I(32种)

8-72T.P.I(32 kinds)

Range of metric threads to be cut

0.5-3mm(18种)

0.5-3mm(18 kinds)

Quill diameter

26mm

1＂

Quill taper

莫氏2号

MT2#

Quill travel

40mm

1-9/16＂

Main motor power

0.55kw

0.75HP

Motor frequency

50HZor 60HZ

Net weight

95kg

209lbs

Floor space dimensions

950×500mm

37-13/32＂×19-16＂

Packing size(L×W×H)

104×56×52cm

41＂×22＂×20-1/2＂

Gross weight

130kg

286lbs
